AL-D190 Decoder IP

Download the leaflet

Allegro DVT’s D190 video decoder family is a multi-format decoder ideal for many applications with its support for sub-frame latency and optmized for HD resolutions. It can support multiple formats including HEVC, AVC and JPEG along with chroma sampling of both 4:2:0 and 4:2:2 and we are providing a core that is highly versatile across a broad range of applications that include:

  • Internet of Things (IoT)
  • Automotive Infotainment
  • Handheld Devices

Key advantages :

  • Optimized core for 1920×1080@60fps resolution
  • Hardware based implementation for minimum area and low power consumption
  • Support of low latency decoding
  • Support of frame buffer compression and decompression
  • Fast and easy integration within a wide range of System-On-Chip (SoC) designs
  • Tested using Allegro DVT’s “industry standard” compliance streams
Supported formats
H.265/HEVC Main, Main 10 and Main 4:2:2 10 profiles, up to Level 4.1 – Main tier and High tier
H.264/AVC Constrained Baseline, Main, High, High 10 and High 4:2:2 profiles, up to Level 4.2
JPEG Baseline
AMBA APB interface for control registers programming
AMBA AXI interfaces for data access
RTL source code
C control software
Bit accurate executable software reference model
